Electrical and Computer Engineering (UG) Infrastructure And Facilities

Name of Laboratory : AC Machines Lab

Area of Laboratory	67.89 sqm
Laboratory Incharge	Dr. L. S. Patil
Laboratory Assistant	Mr. P. V. Sutar
Laboratory Investment	₹8,41,834/-
List of Major Equipment	3 Phase SC Induction Motor & DC Shunt Generator Load Test 3 Phase Synchronous Motor & DC Shunt Generator 3 Phase Slip Ring Induction Motor & DC Shunt Generator 3 Phase 2 KVA Isolation Transformer 3 Phase 20A Dimmer 3 Phase Motor with Brake Load 3 Phase IM Coupled with Generator 3 Phase Alternator Coupled to 3 Phase SCIM

Name of Laboratory : Computer Lab-I

Area of Laboratory	46.82 sqm
Laboratory Incharge	Dr. S. N. Patil
Laboratory Assistant	Mr. V. R. Phalke
Laboratory Investment	₹9,27,860/-
List of Major Equipment	Lenovo ThinkCentre Desktop PC (i5, 4GB RAM, 1TB HDD) Lenovo Colour Monitor 2GB Graphics Card HP LaserJet Printer M1005 Champion UPS

Name of Laboratory : Computer Lab-II

Area of Laboratory	45.52 sqm
Laboratory Incharge	Prof. S. P. Kamble
Laboratory Assistant	Mr. V. R. Phalke
Laboratory Investment	₹8,36,190/-
List of Major Equipment	Lenovo ThinkCentre Desktop PC (i5, 4GB RAM, 1TB HDD) Lenovo Colour Monitor 2GB Graphics Card HP LaserJet Printer M1005 Champion UPS

Name of Laboratory : Computer Lab-III

Area of Laboratory	77.99 sqm
Laboratory Incharge	Prof. S. K. Shaikh
Laboratory Assistant	Mr. V. R. Falke
Laboratory Investment	₹11,80,515/-
List of Major Equipment	Lenovo ThinkCentre Desktop PC (i5, 4GB RAM, 1TB HDD) Lenovo Colour Monitor 2GB Graphics Card HP LaserJet Printer M1005 Wheatstone Bridge, Kelvin Double Bridge Maxwell Bridge Kit, Hay Bridge Kit Anderson Bridge Kit, Schering Bridge Kit Wien Bridge Kit, Owen Bridge Kit Linear Variable Differential Transducer (LVDT) Kit Reciprocity Theorem Chassis Thevenin’s Theorem Chassis Norton’s Theorem Chassis Superposition Theorem Chassis Compensation Theorem Chassis Maximum Power Transfer Theorem Kit

Name of Laboratory : DC Machines Lab

Area of Laboratory	67.35 sqm
Laboratory Incharge	Dr. L. S. Patil
Laboratory Assistant	Mr. P. V. Sutar
Laboratory Investment	₹5,00,000/-
List of Major Equipment	15 kW DC Power Supply Rectifier Unit (Static) 14 kW DC Power Supply Rectifier Unit (Dynamic) DC Motor & Generator Set DC Motor & Alternator Set DC Motor & DC Shunt Generator DC Motor & DC Compound Generator DC Shunt Motor with Brake Load Test DC Generator Coupled to Induction Motor

Name of Laboratory : Electrical Drives Lab

Area of Laboratory	58.74 sqm
Laboratory Incharge	Prof. M. C. Butale
Laboratory Assistant	Mr. P. V. Sutar
Laboratory Investment	₹8,53,000/-
List of Major Equipment	SCR / TRIAC / DIAC / MOSFET / IGBT Characteristics Kit Single Phase Full Wave Bridge Converter Feeding DC Motor Kit Morgan’s Chopper Kit Three-Phase Induction Motor Control using PWM Inverter with V/F Scheme DSO (TBS1052B, 50–200 MHz) Three Phase Fully Controlled Converter (Microcontroller based firing, 1000W lamp load, 5A output) Chopper Circuit using Power MOSFET for Motor Control (¼ HP, 110V DC Series Motor, spring balance, speed indicator) Three Phase Induction Controller using Slip Power Recovery Scheme 3 Phase Induction Motor Controller using V/F Scheme and PWM Method (0.5 HP, above base speed) Chopper Circuit using Power MOSFET for Motor Control (Microcontroller based firing, DC motor, isolated output)

Name of Laboratory : P. G. Lab.

Area of Laboratory	78 sqm
Laboratory Incharge	Prof. S. A. Patil
Laboratory Assistant	Mr. V. R. Phalke
Laboratory Investment	₹8,36,190/-
List of Major Equipment	Lenovo ThinkCentre Desktop PC (i5, 4GB RAM, 1TB HDD) Lenovo Colour Monitor 2GB Graphics Card HP LaserJet Printer M1005 Champion UPS

Name of Laboratory : Switchgear Protection Lab.

Area of Laboratory	78.42 sqm
Laboratory Incharge	Dr. S. Y. Gadgune
Laboratory Assistant	Mr. P. V. Sutar
Laboratory Investment	₹13,72,000/-
List of Major Equipment	Electromechanical Phase Fault Relays Kit with Source Unit Electromechanical Earth Fault Relays Kit with Source Unit Electromechanical Over Voltage Relays Kit with Source Unit Electromechanical Over Current Relay Kit with Source Unit Electromechanical Directional Over Current Relay Kit with Source Unit Microprocessor Based Over Current Relay with Differential Characteristics Kit Microprocessor Based Earth Fault / Over & Under Voltage Relay Kit Microprocessor Based Impedance Relay Kit Microprocessor Based Directional Over Current Relay Kit Differential Relay Kit with Source Unit Relay Test Kit with Source Unit
